Introduction
features
- High Discharge Voltage Platform 3.9V.
- High Discharge,C-rate 10C+.
- High Energy Density 260Wh/kg+.
- Strong deep discharge, 1C discharge DOD reaches 100%.
application
- Vertical take-off and landing UAV (eVTOL)
- exploration UAV
- weather UAV
- decoy UAV
- Surveying UAV
- inspection/surveillance UAV
Introduction
features
- High Discharge Voltage Platform 3.9V.
- High Discharge,C-rate 10C+.
- High Energy Density 260Wh/kg+.
- Strong deep discharge, 1C discharge DOD reaches 100%.
application
- Vertical take-off and landing UAV (eVTOL)
- exploration UAV
- weather UAV
- decoy UAV
- Surveying UAV
- inspection/surveillance UAV
ALL MODELS
Model | Capacity | Energy(Wh) | Cont. Discharge Current | Max discharge current(A/0.3S) | Size(L*W*H)±2mm | Weight (kg) | Energy Density (Wh/kg） |
EN-25A023A-EHV | 25000mAh 23.1V 6S1P | 577.5 | 250A/10C | 500A/20C | 205*93*67 | 2.54 | 228 |
EN-25A046B-EHV | 25000mAh 46.2V 12S1P | 1155 | 205*93*130 | 4.88 | 237 | ||
EN-25A053I-EHV | 25000mAh 53.9V 14S1P | 1347.5 | 205*93*151 | 5.66 | 239 | ||
EN-30A023D-EHV | 30000mAh 23.4V 6S1P | 702 | 300A/10C | 600A/20C | 208*101*70 | 2.87 | 245 |
EN-30A046H-EHV | 30000mAh 46.8V 12S1P | 1404 | 208*101*136 | 5.54 | 254 | ||
EN-30A054F-EHV | 30000mAh 54.6V 14S1P | 1638 | 208*101*158 | 6.43 | 255 | ||
EN-32A023D-EHV | 32000mAh 23.4V 6S1P | 748.8 | 222*101*70 | 3.04 | 246 | ||
EN-32A046H-EHV | 32000mAh 46.8V 12S1P | 1497.6 | 320A/10C | 640A/20C | 222*101*136 | 5.89 | 255 |
EN-32A054F-EHV | 32000mAh 54.6V 14S1P | 1747.2 | 222*101*158 | 6.84 | 256 | ||
EN-50A023A-EHV | 50000mAh 23.1V 6S2P | 1155 | 500A/10C | 1000A/20C | 205*93*130 | 4.88 | 237 |
EN-50A046B-EHV | 50000mAh 46.2V 12S2P | 2310 | 205*93*256 205*185*128 | 9.56 | 242 | ||
EN-50A053I-EHV | 50000mAh 53.9V 14S2P | 2695 | 205*93*298 205*185*149 | 11.12 | 243 | ||
EN-64A046H-EHV | 64000mAh 46.8V 12S2P | 2995 | 640A/10C | 1280A/20C | 222*101*268 222*200*135 | 12.18 | 246 |
EN-64A070B-EHV | 64000mAh 70.2V 18S2P | 4493 | 222*101*400 222*200*201 | 18.06 | 249 | ||
EN-60A046H-EHV | 60000mAh 46.8V 12S2P | 2808 | 600A/10C | 1200A/20C | 208*101*269 208*200*137 | 10.88 | 259 |
EN-60A070B-EHV | 60000mAh 70.2V 18S2P | 4212 | 208*101*401 208*200*203 | 16.22 | 260 | ||
EN-75A046B-EHV | 75000mAh 46.2V 12S3P | 3465 | 750A/10C | 1200A/20C | 205*93*383 205*185*194 | 14.24 | 244 |
EN-75A069C-EHV | 75000mAh 69.3V 18S3P | 5197.5 | 205*93*572 205*185*194 | 21.26 | 245 | ||
EN-90A046H-EHV | 90000mAh 46.8V 12S3P | 4212 | 900A/10C | 1200A/20C | 208*101*396 208*200*187 | 16.22 | 260 |
EN-90A070B-EHV | 90000mAh 70.2V 18S3P | 6318 | 208*101*599 208*200*302 | 24.23 | 261 |
datasheet-high voltage li-po battery (EHV)
