Introduction
features
- Ultralight, Capacity Increase 20%+.
- Ultra-high Energy Density 320Wh/kg+.
- Cont. Discharge, 3C+.
- Burst Discharge 10C+.
- Semi-solid Polymer.
application
- Vertical take-off and landing UAV (eVTOL)
- exploration UAV
- weather UAV
- decoy UAV
- Surveying UAV
- inspection/surveillance UAV
Introduction
features
- Ultralight, Capacity Increase 20%+.
- Ultra-high Energy Density 320Wh/kg+.
- Cont. Discharge, 3C+.
- Burst Discharge 10C+.
- Semi-solid Polymer.
application
- Vertical take-off and landing UAV (eVTOL)
- exploration UAV
- weather UAV
- decoy UAV
- Surveying UAV
- inspection/surveillance UAV
ALL MODELS
ALL MODELS
Model | Capacity | Series | Size(L*W*H)±2mm | Weight (g) | C rating |
 EN-17A022S-EXE | 17000mAh | 22.2V 6S1P | 51*74*180 | 1500 | 10C |
| EN-17A044T-EXE | 44.4V 6S1P | 100.5*74*180 | 1850 | ||
EN-17A051F-EXE | 51.8V 14S1P | 116.5*74*180 | 3300 | ||
EN-17A066E-EXE | 66.6V 18S1P | 149.5*74*180 | 4200 | ||
| EN-22A022S-EXE | 22000mAh | 22.2V 6S1P | 63.5*74*180 | 1915 | 10C |
| EN-22A044T-EXE | 44.4V 6S1P | 125.5*74*180 | 3680 | ||
EN-22A051F-EXE | 51.8V 14S1P | 146.5*74*180 | 4260 | ||
EN-22A066E-EXE | 66.6V 18S1P | 187.5*74*180 | 5440 | ||
| EN-25A022S-EXE | 25000mAh | 22.2V 6S1P | 42*107*240 | 2390 | 10C |
EN-25A044T-EXE | 44.4V 6S1P | 82.5*107*240 | 4630 | ||
EN-25A051F-EXE | 51.8V 14S1P | 96*107*240 | 5380 | ||
EN-25A066E-EXE | 66.6V 18S1P | 122.5*107*240 | 6880 | ||
EN-27A022S-EXE | 27000mAh | 22.2V 6S1P | 60.5*89*200 | 2340 | 10C |
EN-27A044T-EXE | 44.4V 6S1P | 119.5*89*200 | 4530 | ||
EN-27A051F-EXE | 51.8V 14S1P | 139.5*89*200 | 5260 | ||
EN-27A066E-EXE | 66.6V 18S1P | 178.5*89*200 | 6720 | ||
EN-30A022S-EXE | 30000mAh | 22.2V 6S1P | 66.5*89*200 | 2580 | 10C |
EN-30A046T-EXE | 44.4V 6S1P | 131.5*89*200 | 5020 | ||
EN-30A053F-EXE | 51.8V 14S1P | 153*89*200 | 5830 | ||
EN-30A066E-EXE | 66.6V 18S1P | 196.5*89*200 | 7450 | ||
| EN-40A022S-EXE | 40000mAh | 22.2V 6S1P | 64.5*107*240 | 3610 | 10C |
| EN-40A044T-EXE | 44.4V 6S1P | 126*107*240 | 7080 | ||
EN-40A051F-EXE | 51.8V 14S1P | 147.5*107*240 | 8240 | ||
EN-40A066E-EXE | 66.6V 18S1P | 189*107*240 | 10550 |
datasheet-Extra high energy semi-solid battery (EXE)
PLUGS
Authentication
ISO9001
ISO14001
ISO45001
CE
Quick inquiry
Drop us a line, and we’ll get back to you within 24 hours.
Need a Custom Battery Solution?
Submit your requirements via the form, and our team will deliver OEM/ODM options tailored to your drone.
other SERIES
features
- High Discharge C-rate , Bust up to 50C.
- High Capacity, Long Endurance.
- Strong deep discharge, 1C discharge DOD reaches 100%.
application
- All kinds of agricultural UAV
- Multi-axis UAV helicopter
- fixed wing UAV
- aerialcamera
- weather UAV
features
- High Discharge C-rate , Burst up to 150C+.
- Strong deep discharge, 1C discharge DOD reaches 100%.
- Safety and Stability.
application
- FPV traversing machine
- model aircraft UAV
- remote control car
- remote control boat
- electric helicopter
features
- BMS system.
- High Current Discharge & Low Temperature Rise.
- Aluminum case to enhance mechanical impact strength and heat dissipation.
- SOC/SOH display; Manual switch, automatic sleep function.
application
- Plant protection drones
- transportation drones
